| Details: The machine has multiple processing to realize feeding, punching, countersinking, cutting and piece’s ejecting at same time. Holes punching adopt hydraulic station with high pressure that allows the realization of precise machining. This machine is the right solution for alum...
| Details:
The machine has multiple processing to realize feeding, punching, countersinking, cutting and piece’s ejecting at same time. Holes punching adopt hydraulic station with high pressure that allows the realization of precise machining. This machine is the right solution for aluminum hinges making. The working cycle is fully automatic, each piece production time is only 3~4 second. Servo driver high precise feeder is optional.
| Technical parameter:
| Power supply | 3-phase, 415/380V, 50HZ |
| Rated power | 4.0 KW |
| Operation air pressure | 0.5-0.8Mpa |
| Auto-feeding length | 5-300mm |
| Saw blade spec. | D350mm |
| Overall dimensions | 6200x1000x1700mm |
| Weight | 600 KG (appr.) |
